HPE Networking Instant On 1840 8P Gigabit + 1P CL3 PD là một giải pháp mạng nhỏ gọn, tiết kiệm chi phí, được thiết kế cho nhu cầu kết nối mạng Gigabit tại các văn phòng nhỏ, cửa hàng bán lẻ, quán café và các hệ thống SMB, cung cấp kết nối Layer 2 Gigabit cùng khả năng quản lý trực quan qua Cloud Portal, Mobile App và giao diện Web.
8 Port Gigabit Ethernet: Switch được trang bị 8 cổng RJ-45 10/100/1000BASE-T, trong đó 1 cổng hỗ trợ IEEE 802.3af Class 3 PD để nhận nguồn PoE và 7 cổng Gigabit còn lại dành cho kết nối thiết bị mạng.
PoE Class 3 PD: Cổng số 1 hỗ trợ Class 3 Powered Device (PD), cho phép switch nhận nguồn qua Ethernet từ một thiết bị cấp nguồn PoE (PSE) tương thích. Đây là thiết kế phù hợp khi cần triển khai switch tại những vị trí khó bố trí nguồn điện riêng.
Switching capacity 16 Gbps: Với khả năng chuyển mạch lên tới 16 Gbps, thiết bị đáp ứng tốt nhu cầu truyền tải dữ liệu Gigabit giữa các thiết bị trong mạng nội bộ.
Throughput capacity 41.66 Mpps: Switch đạt hiệu năng chuyển tiếp lên tới 41.66 triệu packets/giây (Mpps) với packet 64 bytes, giúp xử lý hiệu quả lưu lượng mạng trong môi trường SMB
|
Category
|
Specification
|
|
Product Number
|
S5E25A
|
|
Product Name
|
HPE Networking Instant On Switch 8p Gigabit 1p CL3 PD 1840
|
|
Switch Type
|
Layer 2 Gigabit Smart Switch
|
|
Ethernet Ports
|
8 × RJ-45 autosensing 10/100/1000BASE-T
|
|
PoE PD Port
|
1 × RJ-45 with IEEE 802.3af Class 3 PD (Port 1)
|
|
Standard Ethernet Ports
|
7 × RJ-45 10/100/1000BASE-T (Ports 2–8)
|
|
PoE Output
|
Not supported
|
|
SFP Uplink Ports
|
N/A
|
|
Console Port
|
N/A
|
|
Switching Capacity
|
16 Gbps
|
|
Throughput
|
41.66 Mpps @ 64-byte packets
|
|
Jumbo Frames
|
Up to 9216 bytes
|
|
MAC Address Table
|
16,000 entries
|
|
Maximum VLANs
|
64 VLANs
|
|
IGMP Groups
|
1,000 groups
|
|
IPv4/MAC ACL Entries – Ingress
|
50
|
|
IPv4/MAC ACL Entries – Egress
|
Unsupported
|
|
Maximum ACEs
|
2,048
|
|
Link Aggregation Groups (LAG)
|
8
|
|
LAG Members
|
Up to 4 ports per group
|
|
Processor
|
ARM Cortex-A9 @ 1.2 GHz
|
|
SDRAM
|
1 GB DDR4
|
|
Flash Memory
|
256 MB NAND
|
|
Packet Buffer
|
512 KB
|
|
Latency – 100 Mb
|
< 8.8 µs
|
|
Latency – 1000 Mb
|
< 4.7 µs
|
|
MTBF
|
114 years
|
|
Operating Temperature
|
0°C to 40°C (32°F to 104°F)
|
|
Storage Temperature
|
-40°C to 70°C (-40°F to 158°F)
|
|
Operating Humidity
|
15% to 95% @ 40°C, non-condensing
|
|
Storage Humidity
|
15% to 95% @ 60°C, non-condensing
|
|
Maximum Altitude
|
Up to 3 km (10,000 ft)
|
|
Cooling
|
Fanless
|
|
Power Supply
|
External Power Supply
|
|
AC Voltage
|
100–240 VAC
|
|
Power Consumption – 100% Traffic
|
7.4W @ 100–127V; 7.3W @ 200–220V
|
|
PD Input
|
DC 54V / 7.02W
|
|
Power Consumption – Idle
|
5.2W @ 100–127V; 5.2W @ 200–220V
|
|
Management
|
Instant On Cloud Portal, Mobile App, Web Browser, SNMP Manager, Telnet, SSH
|
|
SNMP
|
SNMPv1, v2, v3
|
|
VLAN
|
Up to 64 VLANs
|
|
Spanning Tree
|
STP, RSTP, MSTP
|
|
IGMP Snooping
|
IGMP v1/v2/v3
|
|
Link Aggregation
|
LACP and Static LAG
|
|
LLDP
|
Supported
|
|
LLDP-MED
|
Supported
|
|
DHCP Snooping
|
Supported
|
|
ACL
|
IPv4 and MAC ACL
|
|
Network Access Control
|
IEEE 802.1X, MAC Authentication
|
|
Authentication
|
RADIUS, TACACS+
|
|
Security Features
|
Port Security, IP Source Guard, DHCP Snooping
|
|
QoS
|
CoS, DSCP, IEEE 802.1p, WRR, Strict Priority Queuing
|
|
Port Mirroring
|
Supported
|
|
RSPAN
|
Supported
|
|
Auto VLAN
|
Supported
|
|
Jumbo Frame Support
|
Up to 9216 bytes
|
|
Dimensions (D × W × H)
|
6.50 × 10.00 × 1.73 in (16.50 × 25.40 × 4.40 cm)
|
|
Weight
|
2.50 lb (1.13 kg)
|
|
Mounting
|
Table-top, wall-mount, under-table mounting
|
|
Warranty/Support
|
Instant On Limited Lifetime Support
|
